Stato Usato: Ottime Condizioni
80 watts (into 8 ohms) x 7 ch Amps • HDMI (V1.1) Repeating: 2-In / 1-Out • All discrete amplifier stages • x3 Assignable Components Inputs • 32 bit DSP • 192 kHz/24-bit D/A converters for all channels • Dolby Digital EX, Pro Logic IIx (Movie/Music/Game), • DTS 96/24, ES (Discrete 6.1/Matrix6.1), Neo:6 (Cinema/Music) • SRS Circle surround II (Cinema/Music/Mono) • Dolby Headphone • Pure Direct mode • On Screen Display • Component video switching (3 in/ 1 out) • x3 Optical / x2 Coaxial digital inputs (4 assignable) • 2nd Zone Audio Output (Same Source) • 50 AM/FM station presets • Improved Station naming • Simple setup menu • Display dimmer • D-BUS (RC-5 In/Out) • Direct IR Flasher Input remote connection • Detachable power cord • Front panel A/V/Optical inputs • Learning Backlight system remote
Caratteristiche Tecniche
| Number of Channels | 7 |
|---|---|
| THX | - |
| DTS | ES, Discrete 6.1/Matrix 6.1, Neo-6 |
| Dolby Digital EX | Yes |
| Dolby Pro Logic IIx | Yes |
| Circle Surround II | Yes |
Sound Enhancements:
| HDCD Decoder | Yes |
|---|---|
| Current Feedback Topology | Yes |
| Discrete Amplification | Yes |
| Power Transformer | Yes |
| D/A Conversion | 192kHz/24-Bit |
| Digital Signal Processing | Cirrus Logic© 32-Bit |
| Video Off | Yes |
| Source Direct | Yes |
In/Outputs:
| Video | |
|---|---|
| HDMI In | 2 |
| Component In | 3 |
| S-Video In | 5 |
| Composite In | 5 |
| HDMI Out | 1 |
| Component Out | 1 |
| S-Video Out | 2 |
| Composite Out | 2 |
| Audio | |
|---|---|
| Analog L&R In | 8 |
| Analog L&R Out | 3 |
| Digital Optical In | 3 |
| Digital Coaxial In | 2 |
| Digital Optical Out | 1 |
| Digital Coaxial Out | 1 |
| IEEE1394 connection | - |
Specifications:
| Audio Section | |
|---|---|
| Power Output (8 Ohm) | 80W x 7 |
| S/N Ratio | 105dB |
| Freq. Response (Analog In) | 8Hz - 100kHz (+/- 3 dB) |
| Freq. Response (Dig In) | 8Hz - 45kHz (+/- 3 dB) |
| Tuner Section FM | |
|---|---|
| Frequency Range | 87.5 - 108.0MHz |
| S/N Ratio (Mono/Stereo) | Mono/Stereo: 75/70 dB |
| Tuner Section AM | |
|---|---|
| Frequency Range | 520 - 1710kHz |
| S/N Ratio | 50 dB |
| Video Section | |
|---|---|
| Video Freq. Response (Component) | 5Hz - 80MHz (-1 dB) |
| Video Freq. Response (Composite, S-Video) | 5Hz - 8MHz (-1 dB) |
| Signal to Noise | 60dB |
| General | |
|---|---|
| Color | Black |
| Front Panel | Aluminum |
| Remote Control | Learning/Pre-coded with backlight - RC5001SR |
| Power Requirement | AC 120V/60Hz |
| Power Consumption | 450W |
| Dimensions (W" x H" x D") | 440 x 384 x 160mm |
| Weight (Kg) | 11.4kg |
