Network Player : protocollo av upnp con estensione streaming audio riproduzione gapless playlist su dispositivo formati di file audio supportati: dsd lossless: dsf (dsd), diff (dsd), dop (dsd) pcm lossless: flac, apple lossless (alac), wav , audio compresso aiff (lossy): mp3, aac (nel contenitore m4a) tassi di campione audio supportati, profondità bit, numero di canali: pcm, 44.1khz - 384khz, 16 - 32bit, stereo dsd, 2.8mhz, 1bit, stereo (5.6 mhz su lumin s1) tariffe di campionamento e profondità bit: opzione di sovracampionamento dsd per tutti i file fino a 96khz dispositivi di controllo supportati: tutti i modelli di apple ipad (v2 o successivo). richiede ios 5.0 o versioni successive. supporto completo per display retina. caratteristiche dell'app: grafica ad alta risoluzione. memorizzazione nella cache delle illustrazioni.
Caratteristiche Tecniche
| Specifiche | Dettagli |
|---|---|
| DSD SUPPORT | DSD 2.8MHz, 1-bit |
| PCM SUPPORT | Up to 384kHz, 16–32-bit, Stereo |
| ANALOG OUTPUT STAGE | Wolfson WM8741 DAC chips, 1 chip per channel |
| Fully balanced layout with high-quality components | |
| DIGITAL OUTPUT STAGE | BNC SPDIF: |
| PCM 44.1kHz–192kHz, 16–24-bit | |
| DSD (DoP, DSD over PCM) 2.8MHz, 1-bit | |
| POWER SUPPLY | External 100–240V AC auto-ranging |
| PHYSICAL | |
| FINISH | Raw brushed aluminium |
| DIMENSIONS | 240mm (W), 244mm (D), 60mm (H), 2kg |
| STREAMING PROTOCOL | |
| UPnP AV protocol with audio streaming extension (OpenHome) | |
| Roon Ready | |
| Spotify Connect | |
| AirPlay-compatible | |
| Gapless Playback | |
| On-Device Playlist | |
| APP FEATURES | |
| Native support for TIDAL, MQA, Qobuz and TuneIn Radio. | |
| Tidal MQA icons to identify high-res music | |
| Qobuz high-res icons to identify high-res music | |
| Volume control | |
| High-resolution artwork | |
| Artwork caching | |
| Search | |
| Multiple tag handling | |
| Composer tag support | |
| Album-grouping in playlist | |
| Automatic internet links to artists/album/songs | |
| Saving and restoring of playlists (including Tidal and Qobuz) | |
| SUPPORTED AUDIO FILE FORMATS | |
| DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD) | |
| PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF | |
| Compressed (lossy) Audio: MP3 | |
| MQA | |
| INPUT | Ethernet RJ45 network 100Base-T |
| USB storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only) | |
| ANALOGUE AUDIO OUTPUTS | XLR balanced, 4Vrms, pin 2 Hot (6Vrms on X1) |
| RCA unbalanced, 2Vrms (3Vrms on X1) | |
| SUPPORTED CONTROL DEVICES | Apple devices. iOS 11.0 or later (List of supported devices) |
| Android devices. Android 4.0 (Ice Cream Sandwich) or later required | |
| OTHER | Leedh Processing lossless digital volume control |
| Programme of Continuous Development – Firmware-upgradable for further features and enhancements | |
| COMPACT CASE | |
| DSD128 | |
| 5.6MHZ | |
| WOLFSON | |
| WM8741 DAC | |
| FULLY | |
| BALANCED | |
| XLR | |
| OUTPUTS |
