Serie All-New Reference Premiere Dolby Atmos - diffusore da pavimento bass reflex a 2 vie con canale aggiuntivo Dolby Atmos certificato a 2 vie in sospensione pneumatica sul pannello superiore - 2x tweeter (1x frontale, 1x superiore) LTS (Linear Travel Suspension) con diaframma in titanio da 1 pollice dotati di involucro ventilato posteriormente e nuovo sistema di caricamento a tromba proprietario Hybrid Tractrix Horn 90º x 90º con plug di fase modellato a computer e superficie esterna in silicone stampato a compressione.
Caratteristiche Tecniche
Main Channel
| Specification | Value |
|---|---|
| Frequency Response | 32Hz - 25kHz +/- 3dB |
| Sensitivity | 98dB @ 2.83V / 1m |
| Power Handling | 150W / 600W |
| Nominal Impedance | 8 Ohms Compatible |
| Crossover Frequency | 1750Hz |
| High Frequency Driver | 1" Titanium LTS Vented Tweeter with Hybrid Cross-Section Tractrix® Horn |
| Low Frequency Driver | Dual 8" Cerametallic Cone Woofers |
| Enclosure Material | MDF |
| Enclosure Type | Bass Reflex via rear-firing Tractrix® Port |
| Inputs | Dual Binding Posts |
| Height | 43.12" (109.5 cm) |
| Width | 10.90" (27.7 cm) |
| Depth | 19.80" (50.3 cm) |
| Weight | 71 lb (32.2 kg) |
| Finish | Ebony, Walnut, Piano Black |
Height Channel
| Specification | Value |
|---|---|
| Frequency Response | Conforms to Dolby Atmos Specifications |
| Sensitivity | Conforms to Dolby Atmos Specifications |
| Power Handling | 75W / 300W |
| Nominal Impedance | 8 Ohms Compatible |
| Crossover Frequency | 2kHz |
| High Frequency Driver | 1" Titanium LTS Tweeter with Hybrid Tractrix Horn |
| Low Frequency Driver | 6.5" Cerametallic Cone Woofer |
| Enclosure Material | MDF |
| Enclosure Type | Acoustic Suspension |
| Inputs | Single Binding Posts |
