PrimaLuna EVO 200 Power Caratteristiche Tecniche Nuovo amplificatore finale Primaluna EVO 200 Power Amplifier Potenza: in stereo 44 watt x 2 (EL34), in mono 88 watt (EL34) (8 Ohm, 1% THD)Ingressi: 1 x Stereo RCA
Uscite: 4 & 8 & 16 Ohm (stereo), 2 & 4 & 8 Ohm (mono) Risposta in frequenza: 10Hz-65kHz +/- 1dB , 7Hz-95Hz +/- 3dB THD: < 0,1% @ 1W, < 2% @ Potenza nominale Rapporto S/N: 92 dB (stereo), 93 dB (mono) Sensibilità d'ingresso: 870mV Potenza assorbita: 280 watt Valvole montate di serie: 4 - 12AU74 - EL34 Dimensioni (LxAxAxP) 36,6 x 20,6 x 40,4 cm Peso 23 Kg Finiture Disponibili (frontale) Silver Nero
Caratteristiche Tecniche
Specifications | Model EVO 200-4 for EL34 / KT88 |
Power Ultra-Linear | 44 / 45 Watts per channel Stereo 88 / 90 Watts Mono |
Frequency Response | 12 Hz – 65 kHz +/- 1 dB 10 Hz – 95 kHz +/- 3 dB |
THD with AABB | < 0.1% @ 1W; less than 2% at rated power Stereo < 0.17% @ 1W; less than 2% at rated power Mono |
S/N Ratio | 92 dB Stereo / 93 dB Mono |
Input Impedance | 100 kOhm |
Input Sensitivity | 870 / 880 mV for rated power at maximum volume |
Maximum Gain | 26.5 dB / 29 dB (EL34 / KT88) |
Power Consumption | 280 Watts |
Weight | Net weight: 50.6 lbs / 23 kg Shipping Weight: 61.6 lbs / 28 kg |
Dimensions | 15.9" x 14.4" x 8.1" / 405 x 365 x 205 mm (L x W x H) |
Shipping Dimensions | 22.7" x 18.4" x 12.4" / 577 x 468 x 315 mm (L x W x H) |
Inputs | 1 pair Stereo RCA , 1 piece Mono RCA |
Outputs | 4, 8 & 16 / 2, 4 & 8 Ohm Speaker Taps |
Tube Complement | 4 x EL34, 4 x 12AU7 |
Damping Coefficient | 4 KD (1 kHz) |
Remote Control | - |
