Dotato di caricamento del disco silenzioso e fluido, l'elevata rigidità e il baricentro basso dell'unità SA-CD/CD migliora notevolmente la leggibilità, mentre il convertitore D/A di tipo MDS+ con quattro circuiti paralleli legge con precisione le informazioni del disco e converte i segnali analogici. Supporta anche una connessione digitale con un
equalizzatore vocale e fornisce una funzione di playlist programmabile che ti consente di goderti l'ascolto nell'ordine che preferisci. Divertiti ad ascoltare il DP-570, il passo successivo nella ricerca dell'esperienza di riproduzione del disco ideale.
Caratteristiche Tecniche
| Specification | Value |
|---|---|
| Compatible Disc Formats | 2-channel Super Audio CD, CD, DSD disc, DVD-R/-RW/+R/+RW, CD-R/-RW, DVD-R/-RW/+R/+RW |
| Data Read Principle | Non-contact optical pickup |
| Laser Diode Wavelength | SA-CD: 655 nm, CD: 790 nm |
| Transport Outputs | |
| - HS-LINK | Proprietary standard, Dedicated HS-LINK cable |
| - OPTICAL | JEITA CP-1212 compliant, - |
| - COAXIAL | IEC 60958 compliant, 75-ohm coaxial digital cable |
| Digital Inputs | |
| - HS-LINK | Proprietary standard, Dedicated HS-LINK cable |
| - USB | USB 2.0 Hi-Speed (480 Mbps) compliant, USB 2.0 cable with Type B connector |
| - OPTICAL | JEITA CP-1212 compliant, - |
| - COAXIAL | IEC 60958 compliant, 75-ohm coaxial digital cable |
| Sampling Frequencies | |
| - HS-LINK (Ver. 1) | DSD 2.8 MHz (1 bit), PCM 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz (16 to 24 bits) |
| - HS-LINK (Ver. 2) | DSD 2.8 / 5.6 MHz (1 bit), PCM 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 / 352.8 / 384 kHz (16 to 32 bits) |
| - USB | DSD 0+] 0+]$6,2RQO\ (1 bit), PCM 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 / 352.8 / 384 kHz (16 to 32 bits) |
| - OPTICAL | PCM 32 / 44.1 / 48 / 88.2 / 96 kHz (16 to 24 bits) |
| - COAXIAL | PCM 32 / 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz (16 to 24 bits) |
| D/A Converter | 4MDS+ principle |
| Frequency Response | 0.5 to 50,000 Hz (+/-0.5 dB) |
| THD + Noise | 0.0006% (20 to 20,000 Hz) |
| Signal-to-Noise Ratio | 120 dB |
| Dynamic Range | 117 dB |
| Channel Separation | 117 dB (20 to 20,000 Hz) |
| Output Voltage and Impedance | |
| - BALANCED | 2.5 V, 50 ohms, Balanced XLR type |
| - LINE | 2.5 V, 50 ohms, RCA phono jack |
| Output Level Control | - |
| Power Requirements | 120 V, 220 V, 230 V AC (voltage as indicated on rear panel), 50/60 Hz |
| Power Consumption | 18 W |
| Maximum Dimensions | Width: 465 mm (18.3"), Height: 151 mm (6.0"), Depth: 393 mm (15.5") |
| Mass | Net: 19.0 kg (41.9 lbs), In shipping carton: 25 kg (55 lbs) |
